DTE Differential Strut Brace / Girdle for C5 Corvette, All Years

Available Options:
Transmission Type: Transmission Type

$399.95

Model: C5Brace Manufacturers: DTE

Qty:

Reviews

Add to Wish List

Description

DTE is no longer in Bussiness and if you order this you will get the ECS Brace as a substitute.

We've identified the three most common causes for C6 and C5 Corvette driveline failure and engineered the DTE Differential Strut to address and correct those negative issues in a lightweight, compact package. The problem of differential case fracture, transmission case breakage and driveline deflection during hard acceleration on the street, road course or drag strip is a common, inherent problem with the C6 and C5 Corvette that often shears the differential away from the attachment point at the transmission.

This product significantly increases the strength of the differential and transmission assembly for high performance use by spreading the drivetrain stress loading over a greater surface area and to the strongest points of attachment in the C6 Corvette driveline. Superior strength by design was successfully achieved with out adding unnecessary weight to the vehicle.

The main point of weakness and area prone to failure in HP C6 and C5 applications are the mounting pad side covers themselves. The O.E. mounting pad "wings" are completely hollow, therefore lacking any real strength. This unfavorable case design makes them inherently weak for intended high performance, high-powered C6 applications. Additionally, there is no significant structural strength in these hollow "wings" to support the extreme shock loads of high performance street/strip use, therefore they rapidly fatigue, crack and shatter~ often taking the rest of the differential to premature failure with it.

Our new C6 and C5 Differential Strut fills that engineering gap by providing additional driveline strength on top of the differential case itself using the same design principles as the C5 models, which functions in tandem with the current two lower C6 and C5 Corvette differential mounting locations that are already engineered into the Getrag case. All of these driveline strengthening refinements and additional "girdling" around the differential case itself our product provides, culminates to one final solution to preventing catastrophic C6 and C5 Corvette differential failure for HP applications.

Only the strongest materials and hardware are used in its manufacture and the principle of adding driveline strength with out adding unnecessary weight was the engineering goal that was successfully achieved. The M6 model only weighs approx. 17.2 lbs., which is comparable in weight to approx. 2.5 gallons of gasoline.

Each bracket is manufactured using laser-cut, 3/8" thick tempered steel for durability and exact fit. The adjustable strut rods are manufactured of stainless steel and are 9/16" in diameter for strength, while still being lightweight. We also utilize HD, steel-ball Heim joints at both ends for ease of assembly and strut rod durability. All threaded mounting holes deeply threaded to increase thread engagement and surface area for strength.

The entire kit is easily installed or removed while using a lift or jack stands while the driveline is in the car. Lowering of the sub-frame is necessary for easier access to the M6 transmission brackets and is designed to be a true, bolt-on installation kit that can be installed in a few hours using regular, commonly found metric/SAE hand tools. There is also no driveline vibration/noise resonated into the passenger compartment/cabin of any kind and interior sound levels are unaffected from O.E.M.

The DTE Differential Strut is designed to be a true bolt-on drivetrain upgrade for the C6 with a manual transmission and C5 Corvette with a manual or automatic transmission and doesn't require modification to the vehicle of any kind to install. Each kit comes powder coated red or black for corrosion resistance and includes all of the necessary brackets, fasteners, hardware and detailed photo enhanced instructions required for installation.

Kit Design Features and Principles:

The DTE Differential Strut kit is engineered to counter-act the destructive, natural upward, "wrap-up" action of the differential during hard acceleration that is equal to and opposite of the forward motion of the wheels. Adjustable strut rods connect the transmission to the differential by providing a pre-load against this "wrap-up" action, which causes the differential case to fracture at the transmission mounting flange where the two are bolted together. In some severe cases of fracture, the transmission output shaft will also be broken off when the differential breaks away from the transmission.

This differential strut increases the overall strength and rigidity of the diff./trans. assembly as a whole and provides increased stability to the entire rear drivetrain. The steel brackets secured to the transmission bell housing flange and around the differential case cover perimeter, act as strengthening "girdles" that adds mounting flange rigidity by spreading the driveline shock loads over a greater surface area. These strengthening methods significantly decrease differential mounting flange cracks and transmission output shaft failures. The differential girdle also incorporates a steel cross-strut rod that counteracts any possible deflection between the two upper differential girdle area by tying the two sides of the differential brackets together, side-to-side. Each one of the two adjustable steel strut rods are secured to their respective girdle brackets by heavy duty, steel-ball Heim joints at both ends, in addition to each strut rod being independently adjustable to set pre-load of the entire assembly at both ends.

Application:

C5 Corvette with Manual Transmissions or Automatic 4L60E

Complete Kit Includes:

3-piece differential girdle bracket set w/ strut rod mounting blocks (pre-welded)
2-piece transmission bell housing bracket set w/ strut rod mounting blocks (pre-welded)
2 stainless steel adjustable main strut rods w/ integral "hex" machined into body of rod
4 HD steel-ball, Heim joints
1 stainless steel cross-strut rod
Hardened grade 8 fasteners, studs, washers and related hardware
Powder coated red or black finish
Detailed instructions w/ installation photos
DTE decals
Lifetime warranty

This product was added to our catalog on Tuesday 19 July, 2011.
